UPDATE: If you pull down the sample code, it’s not quite working with Swashbuckle yet. It *does* publish the metadata and the actual endpoints work, but it’s not showing up in the OpenAPI spec. Always something.

I just published Wolverine 0.9.10 to Nuget (after a much bigger 0.9.9 yesterday). There’s several bug fixes, some admitted breaking changes to advanced configuration items, and one significant change to the “mediator” behavior that’s described at the section at the very bottom of this post.

The big addition is a new library that enables Wolverine’s runtime model directly for HTTP endpoints in ASP.Net Core services without having to jump through the typical sequence of delegating directly from a Minimal API method directly to Wolverine’s mediator functionality like this:

app.MapPost("/items/create", (CreateItemCommand cmd, IMessageBus bus) => bus.InvokeAsync(cmd));

app.MapPost("/items/create2", (CreateItemCommand cmd, IMessageBus bus) => bus.InvokeAsync<ItemCreated>(cmd));

Instead, Wolverine now has the WolverineFx.Http library to directly use Wolverine’s runtime model — including its unique middleware approach — directly from HTTP endpoints.

Shamelessly stealing the Todo sample application from the Minimal API documentation, let’s build a similar service with WolverineFx.Http, but I’m also going to switch to Marten for persistence just out of personal preference.

To bootstrap the application, I used the dotnet new webapi model, then added the WolverineFx.Marten and WolverineFx.HTTP nugets. The application bootstrapping for basic integration of Wolverine, Marten, and the new Wolverine HTTP model becomes:

using Marten;
using Oakton;
using Wolverine;
using Wolverine.Http;
using Wolverine.Marten;

var builder = WebApplication.CreateBuilder(args);

// Adding Marten for persistence
builder.Services.AddMarten(opts =>
    {
        opts.Connection(builder.Configuration.GetConnectionString("Marten"));
        opts.DatabaseSchemaName = "todo";
    })
    .IntegrateWithWolverine()
    .ApplyAllDatabaseChangesOnStartup();

// Wolverine usage is required for WolverineFx.Http
builder.Host.UseWolverine(opts =>
{
    // This middleware will apply to the HTTP
    // endpoints as well
    opts.Policies.AutoApplyTransactions();

    // Setting up the outbox on all locally handled
    // background tasks
    opts.Policies.UseDurableLocalQueues();
});

// Learn more about configuring Swagger/OpenAPI at https://aka.ms/aspnetcore/swashbuckle
builder.Services.AddEndpointsApiExplorer();
builder.Services.AddSwaggerGen();

var app = builder.Build();

// Configure the HTTP request pipeline.
if (app.Environment.IsDevelopment())
{
    app.UseSwagger();
    app.UseSwaggerUI();
}

// Let's add in Wolverine HTTP endpoints to the routing tree
app.MapWolverineEndpoints();

return await app.RunOaktonCommands(args);

Do note that the only thing in that sample that pertains to WolverineFx.Http itself is the call to IEndpointRouteBuilder.MapWolverineEndpoints().

Let’s move on to “Hello, World” with a new Wolverine http endpoint from this class we’ll add to the sample project:

public class HelloEndpoint
{
    [WolverineGet("/")]
    public string Get() => "Hello.";
}

At application startup, WolverineFx.Http will find the HelloEndpoint.Get() method and treat it as a Wolverine http endpoint with the route pattern GET: / specified in the [WolverineGet] attribute.

As you’d expect, that route will write the return value back to the HTTP response and behave as specified by this Alba specification:

[Fact]
public async Task hello_world()
{
    var result = await _host.Scenario(x =>
    {
        x.Get.Url("/");
        x.Header("content-type").SingleValueShouldEqual("text/plain");
    });

    result.ReadAsText().ShouldBe("Hello.");
}

Moving on to the actual Todo problem domain, let’s assume we’ve got a class like this:

public class Todo
{
    public int Id { get; set; }
    public string? Name { get; set; }
    public bool IsComplete { get; set; }
}

In a sample class called TodoEndpoints let’s add an HTTP service endpoint for listing all the known Todo documents:

[WolverineGet("/todoitems")]
public static Task<IReadOnlyList<Todo>> Get(IQuerySession session)
    => session.Query<Todo>().ToListAsync();

As you’d guess, this method will serialize all the known Todo documents from the database into the HTTP response and return a 200 status code. In this particular case the code is a little bit noisier than the Minimal API equivalent, but that’s okay, because you can happily use Minimal API and WolverineFx.Http together in the same project. WolverineFx.Http, however, will shine in more complicated endpoints.

Consider this endpoint just to return the data for a single Todo document:

// Wolverine can infer the 200/404 status codes for you here
// so there's no code noise just to satisfy OpenAPI tooling
[WolverineGet("/todoitems/{id}")]
public static Task<Todo?> GetTodo(int id, IQuerySession session, CancellationToken cancellation)
    => session.LoadAsync<Todo>(id, cancellation);

At this point it’s effectively de rigueur for any web service to support OpenAPI documentation directly in the service. Fortunately, WolverineFx.Http is able to glean most of the necessary metadata to support OpenAPI documentation with Swashbuckle from the method signature up above. The method up above will also cleanly set a status code of 404 if the requested Todo document does not exist.

Now, the bread and butter for WolverineFx.Http is using it in conjunction with Wolverine itself. In this sample, let’s create a new Todo based on submitted data, but also publish a new event message with Wolverine to do some background processing after the HTTP call succeeds. And, oh, yeah, let’s make sure this endpoint is actively using Wolverine’s transactional outbox support for consistency:

[WolverinePost("/todoitems")]
public static async Task<IResult> Create(CreateTodo command, IDocumentSession session, IMessageBus bus)
{
    var todo = new Todo { Name = command.Name };
    session.Store(todo);

    // Going to raise an event within out system to be processed later
    await bus.PublishAsync(new TodoCreated(todo.Id));

    return Results.Created($"/todoitems/{todo.Id}", todo);
}

The endpoint code above is automatically enrolled in the Marten transactional middleware by simple virtue of having a dependency on Marten’s IDocumentSession. By also taking in the IMessageBus dependency, WolverineFx.Http is wrapping the transactional outbox behavior around the method so that the TodoCreated message is only sent after the database transaction succeeds.

Lastly for this page, consider the need to update a Todo from a PUT call. Your HTTP endpoint may vary its handling and response by whether or not the document actually exists. Just to show off Wolverine’s “composite handler” functionality and also how WolverineFx.Http supports middleware, consider this more complex endpoint:

public static class UpdateTodoEndpoint
{
    public static async Task<(Todo? todo, IResult result)> LoadAsync(UpdateTodo command, IDocumentSession session)
    {
        var todo = await session.LoadAsync<Todo>(command.Id);
        return todo != null
            ? (todo, new WolverineContinue())
            : (todo, Results.NotFound());
    }

    [WolverinePut("/todoitems")]
    public static void Put(UpdateTodo command, Todo todo, IDocumentSession session)
    {
        todo.Name = todo.Name;
        todo.IsComplete = todo.IsComplete;
        session.Store(todo);
    }
}

In the WolverineFx.Http model, any bit of middleware that returns an IResult object is tested by the generated code to execute any IResult object returned from middleware that is not the built in WolverineContinue type and stop all further processing. This is intended to enable validation or authorization type middleware where you may need to filter calls to the inner HTTP handler.

With the sample application out of the way, here’s a rundown of the significant things about this library:

• It’s actually a pretty small library in the greater scheme of things and all it really does is connect ASP.Net Core’s endpoint routing to the Wolverine runtime model — and Wolverine’s runtime model is likely going to be somewhat more efficient than Minimal API and much more efficient that MVC Core
• It can be happily combined with Minimal API, MVC Core, or any other ASP.Net Core model that exploits endpoint routing, even within the same application
• Wolverine is allowing you to use the Minimal API IResult model
• The JSON serialization is strictly System.Text.Json and uses the same options as Minimal API within an ASP.Net Core application
• It’s possible to use Wolverine middleware strategy with the HTTP endpoints
• Wolverine is trying to glean necessary metadata from the method signatures to feed OpenAPI usage within ASP.Net Core without developers having to jump through hoops adding attributes or goofy TypedResult noise code just for Swashbuckle
• This model plays nicely with Wolverine’s transactional outbox model for common cases where you need to both make database changes and publish additional messages for background processing in the same HTTP call. That’s a bit of important functionality that I feel is missing or is clumsy at best in many leading .NET server side technologies.

For the handful of you reading this that still remember FubuMVC, Wolverine’s HTTP model retains some of FubuMVC’s old strengths in terms of still not ramming framework concerns into your application code, but learned some hard lessons from FubuMVC’s ultimate failure:

• FubuMVC was an ambitious, sprawling framework that was trying to be its own ecosystem with its own bootstrapping model, logging abstractions, and even IoC abstractions. WolverineFx.Http is just a citizen within the greater ASP.Net Core ecosystem and uses common .NET abstractions, concepts, and idiomatic naming conventions at every possible turn
• FubuMVC relied too much on conventions, which was great when the convention was exactly what you needed, and kinda hurtful when you needed something besides the exact conventions. Not to worry, WolverineFx.Http let’s you drop right down to the HttpContext level at will or use any of the IResult objects in existing ASP.Net Core whenever the Wolverine conventions don’t fit.
• FubuMVC could technically be used with old ASP.Net MVC, but it was a Frankenstein’s monster to pull off. Wolverine can be mixed and matched at will with either Minimal API, MVC Core, or even other OSS projects that exploit ASP.Net Core endpoint routing.
• Wolverine is trying to play nicely in terms of OpenAPI metadata and security related metadata for usage of standard ASP.Net Core middleware like the authorization or authentication middleware
• FubuMVC’s “Behavior” model gave you a very powerful “Russian Doll” middleware ability that was maximally flexible — and also maximally inefficient in runtime. Wolverine’s runtime model takes a very different approach to still allow for the “Russian Doll” flexibility, but to do so in a way that is more efficient at runtime than basically every other commonly used framework today in the .NET community.
• When things went boom in FubuMVC, you got monumentally huge stack traces that could overwhelm developers who hadn’t had a week’s worth of good night sleeps. It sounds minor, but Wolverine is valuable in the sense that the stack traces from HTTP (or message handler) failures will have very minimal Wolverine related framework noise in the stack trace for easier readability by developers.

Big Change to In Memory Mediator Model

I’ve been caught off guard a bit by how folks have mostly been interested in Wolverine as an alternative to MediatR with typical usage like this where users just delegate to Wolverine in memory within a Minimal API route:

app.MapPost("/items/create2", (CreateItemCommand cmd, IMessageBus bus) => bus.InvokeAsync<ItemCreated>(cmd));

With the corresponding message handler being this:

public class ItemHandler
{
    // This attribute applies Wolverine's EF Core transactional
    // middleware
    [Transactional]
    public static ItemCreated Handle(
        // This would be the message
        CreateItemCommand command,

        // Any other arguments are assumed
        // to be service dependencies
        ItemsDbContext db)
    {
        // Create a new Item entity
        var item = new Item
        {
            Name = command.Name
        };

        // Add the item to the current
        // DbContext unit of work
        db.Items.Add(item);

        // This event being returned
        // by the handler will be automatically sent
        // out as a "cascading" message
        return new ItemCreated
        {
            Id = item.Id
        };
    }
}

Prior to the latest release, the ItemCreated event in the handler above when used from IMessageBus.InvokeAsync<ItemCreated>() was not published as a message because my original assumption was that in that case you were using the return value explicitly as a return value. Early users have been surprised that the ItemCreated was not published as a message, so I just changed the behavior to do so to make the cascading message behavior be more consistent and what folks seem to actually want.

After plenty of keystone cops shenanigans with CI automation today that made me question my own basic technical competency, there’s a new Wolverine 0.9.8 release on Nuget today with a variety of fixes and some new features. The documentation website was also re-published.

First, some thanks:

• Wojtek Suwala made several fixes and improvements to the EF Core integration
• Ivan Milosavljevic helped fix several hanging tests on CI, built the MemoryPack integration, and improved the FluentValidation integration
• Anthony made his first OSS contribution (?) to help fix quite a few issues with the documentation
• My boss and colleague Denys Grozenok for all his support with reviewing docs and reporting issues
• Kebin for improving the dead letter queue mechanics

The highlights:

• Improved middleware usability and actual documentation on the same
• “Compound Handlers” — more on this later. From our efforts converting a large system to Wolverine this is going to help with message handler testability
• MemoryPack integration for lightning fast serialization
• The `AutoApplyTransactions()` option (for Marten or for EF Core). This also enables folks to mix and match EF Core & Marten against the same Postgresql database within the same application
• I added .NET 6 support back in, but the CI is only testing against 7.0

Dogfooding baby!

Conveniently enough, I’m part of a little officially sanctioned skunkworks team at work experimenting with converting a massive distributed monolithic application to the full Marten + Wolverine “critter stack.” I’m very encouraged by the effort so far, and it’s driven some recent features in Wolverine’s execution model to handle complexity in enterprise systems. More on that soon.

It’s also pushing the story for interoperability with NServiceBus on the other end of Rabbit MQ queues. Strangely enough, no one is interested in trying to convert a humongous distributed system to Wolverine in one round of work. Go figure.

When will Wolverine hit 1.0?

There’s a little bit of awkwardness in that Marten V6.0 (don’t worry, that’s a much smaller release than 4/5) needs to be released first and I haven’t been helping Oskar & Babu with that recently, but I think we’ll be able to clear that soon.

My “official” plan is to finish the documentation website by the end of February and make the 1.0 release by March 1st. Right now, Wolverine is having its tires kicked by plenty of early users and there’s plenty of feedback (read: bugs or usability issues) coming in that I’m trying to address quickly. Feature wise, the only things I’m hoping to have done by 1.0 are:

• Using more native capabilities of Azure Service Bus, Rabbit MQ, and AWS SQS for dead letter queues and delayed messaging. That’s mostly to solidify some internal abstractions.
• It’s a stretch goal, but have Wolverine support Marten’s multi-tenancy through a database per tenant strategy. We’ll want that for internal MedeAnalytics usage, so it might end up being a priority
• Some better integration with ASP.Net Core Minimal API

Marten was conceived and launched way back in 2016 as an attempt to quickly improve the performance and stability of a mission critical web application by utilizing Postgresql and its new JSON capabilities as a replacement for a 3rd party document database – and do that in a hurry before the next busy season. My former colleagues and I did succeed in that endeavor, but more importantly for the longer run, Marten was also launched as an open source project on GitHub and quickly attracted attention from other developers. The addition of an originally small feature set for event sourcing dramatically increased interest and participation in Marten.

Fast forward to today, and we have a vibrant community of engaged users and a core team of contributors that are constantly improving the tool and discussing ideas about how to make it even better. The giant V4 release last year brought an overhaul of almost all the library internals and plenty of new capabilities. V5 followed early in 2022 with more multi-tenancy options and better tooling for development lifecycles and database management based on early issues with V4.

At this point, I’d list the strong points of Marten that we’ve already achieved as:

• A very useful document database option that provides the powerful developer productivity you expect from NoSQL solutions while also supporting a strong consistency model that’s usually missing from NoSQL databases.
• A wide range of viable hosting options by virtue of being on top of Postgresql. No cloud vendor lock-in with Marten!
• Quite possibly the easiest way to build an application using Event Sourcing in .NET with both event storage and user defined view projections in the box
• A great local development story through the simple ability to run Postgresql in a Docker container and Marten’s focus on an “it just works” style database schema management subsystem
• The aforementioned core team and active user base makes Marten a viable OSS tool for teams wanting some reassurance that Marten is going to be well supported in the future

Great! But now it’s time to talk about the next steps we’re planning to take Marten to even greater heights in the forthcoming Marten V6 that’s being planned now. The overarching theme is to remove the most common hurdles for not choosing Marten. By and large, I think the biggest themes for Marten are:

1. Scalability, so Marten can be used for much larger data sets. From user feedback, Marten is able to handle data sets of 10 million events today, but there’s opportunities to go far, far larger than that.
2. Improvements to operational support. Database migrations when documents change, rebuilding projections without downtime, usage metrics, and better support for using multiple databases for multi-tenancy
3. Marten is in good shape as a purely storage option for Event Sourcing, but users are very often asking for an array of subscription options to propagate events captured by Marten
4. More powerful options for aggregating event data into more complex projected views
5. Improving the Linq and other querying support is a seemingly never-ending battle
6. The lack of professional support for Marten. Obviously a lot of shops and teams are perfectly comfortable with using FOSS tools knowing that they may have to roll up their sleeves and pitch in with support, but other shops are not comfortable with this at all and will not allow FOSS usage for critical functions. More on this later.

First though, Marten is getting a new “critter” friend in the larger JasperFx project family:

Wolverine is a new/old OSS command bus and messaging tool for .NET. It’s what was formerly being developed as Jasper, but the Marten team decided to rebrand the tool as a natural partner with Marten (both animals plus Weasel are members of the Mustelidae family). While both Marten and Wolverine are happily usable without each other, we think that the integration of these tools gives us the opportunity to build a full fledged platform for building applications in .NET using a CQRS architecture with Event Sourcing. Moreover, we think there’s a significant gap in .NET for this kind of tooling and we hope to fill that.

So, onto future plans…

There’s a couple immediate ways to improve the scalability of Marten we’re planning to build in Marten V6. The first idea is to utilize Postgresql table sharding in a couple different ways.

First, we can enable sharding on document tables based on user defined criteria through Marten configuration. The big challenge there is to provide a good migration strategy for doing this as it requires at least a 3 step process of copying the existing table data off to the side before creating the new tables.

The next idea is to shard the event storage tables as well, with the immediate idea being to shard off of archived status to effectively create a “hot” storage of recent events and a “cold” storage of older events that are much less frequently accessed. This would allow Marten users to keep the active “hot” event storage to a much smaller size and therefore greatly improve potential performance even as the database continues to grow.

We’re not done “sharding” yet, but this time we need to shift to the asynchronous projection support in Marten. The core team has some ideas to improve the throughput of the asynchronous projection code as it is, but today it’s limited to only running on one single application node with “hot/cold” rollover support. With some help from Wolverine, we’re hoping to build a “sharded” asynchronous projection that can shard the processing of single projections and distribute the projection work across potentially many nodes as shown in the following diagram:

The asynchronous projection sharding is going to be a big deal for Marten all by itself, but there’s some other potentially big wins for Marten V6 with better tooling for projection rebuilds and asynchronous projections in general:

1. Some kind of user interface to monitor and manage the asynchronous projections
2. Faster projection rebuilds
3. Zero downtime projection rebuilds

Marten + Wolverine == “Critter Stack”

Again, both Marten and Wolverine will be completely usable independently, but we think there’s some potential synergy through the combination. One of the potential advantages of combining the tools is to use Wolverine’s messaging to give Marten a full fledged subscription model for Marten events. All told we’re planning three different mechanisms for propagating Marten events to the rest of your system:

1. Through Wolverine’s transactional outbox right at the point of event capture when you care more about immediate delivery than strict ordering (this is already working)
2. Through Martens asynchronous daemon when you do need strict ordering
3. If this works out, through CDC event streaming straight from the database to Kafka/Pulsar/Kinesis

That brings me to the last topic I wanted to talk about in this post. Marten and Wolverine in their current form will remain FOSS under the MIT license, but it’s past time to make a real business out of these tools.

I don’t know how this is exactly going to work out yet, but the core Marten team is actively planning on building a business around Marten and now Wolverine. I’m not sure if this will be the front company, but I personally have formed a new company named “Jasper Fx Software” for my own activity – but that’s going to be limited to just being side work for at least awhile.

The general idea – so far – is to offer:

• Support contracts for Marten
• Consulting services, especially for help modeling and maximizing the usage of the event sourcing support
• Training workshops
• Add on products that add the advanced features I described earlier in this post

Maybe success leads us to offering a SaaS model for Marten, but I see that as a long way down the road.

What think you gentle reader? Does any of this sound attractive? Should we be focusing on something else altogether?
